Product Specification
Display screen: 3.5 inch full viewing angle TFT screen
Infrared Image Resolution: 384 * 288
Display screen resolution:640 * 480
Field angle/shortest focus length :13mm
Thermal sensitivity:≤60mk@25℃,F#1.0
Temperature measurement range:-20℃ to 550℃ (-4°F to 1022°F)
Measurement accuracy:±2% digital / ±2℃
Emissivity:Adjustable from 0.01 to 1.0
Frame rate of thermal images:25Hz /50Hz
Storage medium:Built-in 3G(above 20 thousand image stored)
Power supply:built-in chargeable 26650mAh battery
Automatic power-off time"selectable:5 minutes/20 minutes/not power off automatically
Product size(length*width*height):97mm*129mm*256mm
Work temperature:0℃ to 45℃
Storage temperature:-20℃ to 60℃
Relative humidity:<85%RH
Package List:
1 * Thermal Imaging Camera 1 * User Manual 1 * USB Line 1 * Protection bag
