High Speed 2D BARCODE SCANNER
Description:
This QR 2D 1D handheld barcode scanner is with USB Wired Connection, It's an effective barcode scanner work for you. It supports powerful bar code decoding capabilities, fast scanning speed, long transmission distance, a lightweight and durable appearance. What's more, it does'n need install or download any software, drivers or apps, just plug and play easily.
Features:
- Support work well with Desktop & Laptop via USB cable.
- Plug and Play, no need to download apps, no need to install software drive.
- Simple installation and ideal use in a wide range of situations and workplaces.
- Two working mode: Instant upload mode / storage mode. Internal offline storage supports up to 100,00 barcodes in offline storage mode.
- Scan and store barcode when far away from the receiver,and then update the data to your device when you come back entering the wireless transmission range.
Package：
2D Wired Barcode Scanner*1
Specification ：
| Performance | Sensor | 640*480 CMOS | |||||||
| Symbologies | 1D | EAN-8、EAN-13、EAN-13 2 add-on、 EAN-13 5 add-on、ISSN、ISBN、UPC-A、UPC-E、Code 11、Code 32、Code 39、Code 39FULLASCII、Code 93、Code 128、Codabar、Industrial 2 of 5、Interleaved 2 of 5、Matrix 2 of 5、ISBT-128、GS1-128、GS1 DataBar（RSS14）、 GS1 DataBar Limited、GS1 DataBar Expanded | |||||||
| 2D | PDF417,MicroPDF417,MicroQR, Data Matrix,QR,Aztec | ||||||||
Depth of field | Tested code | Min | Max | ||||||
| UPC-13mil | 4cm | 35cm | |||||||
| 20 mil code39 | 7cm | 50cm | |||||||
| 20 mil QR Code | 2cm | 30cm | |||||||
| OS compatibility | Linux，Android，Windows XP,7, 8,10，MacOS | ||||||||
| Scan Mode | Manual Scan, Auto Scan | ||||||||
| Countries Keyboards | American-English, French, Italian, German, Spanish, Finnish, Japanese, Russian, Arabic, Irish, Polish, Dutch, Czech, Portuguese (Portuguese, Brazilian), Swedish, Turkish F, Turkish Q , Greek, Belgian-French、UK-English | ||||||||
| Language | Simplified Chinese characters (under Win system) | ||||||||
| Invoice Function | Support (only for the Chinese market) (under Win system) | ||||||||
| Min resolution | Code 39 4mil | ||||||||
| Decode capacity | 1D/2D Codes on printed paper and mobile screen | ||||||||
| Motion Tolerance | 2.8 meters/sec | ||||||||
| Print contrast | 25% | ||||||||
| Secondary development | Not support | ||||||||
| Data output editing | Prefix&suffix | ||||||||
| Scan Angle | Roll ±360°，Pitch ±60°，Skew ±70° | ||||||||
| Environmental | Drop | Withstand 5 drops from 2 meters | |||||||
| Sealing | IP54 | ||||||||
| Operating Temperature | -20-55℃ | ||||||||
| Storage Temperature | -20-60℃ | ||||||||
| Operating Humidity | 5-95% Non-condensing | ||||||||
| Storage Humidity | 5-95% Non-condensing | ||||||||
| Ambient Light | 0-70000LUX | ||||||||
| Trigger | Trigger Scan | ||||||||
| Indicator light | Blue power indicator, decoding flashes | ||||||||
| Buzzer | Start prompt, decoding success prompt | ||||||||
| Net weight | 100g | ||||||||
| Gross Weight | 300g | ||||||||
| Dimension | 168mm*85mm*62mm | ||||||||
| Packing | 240*140*89mm | ||||||||
| Cable length | 180CM(±3CM) | ||||||||
| Interface | USB port (free drive), USB virtual serial port (installation driver), serial port (free drive) | ||||||||
| Voltage | 5V | ||||||||
| USB Manual Scan | Standby Power | 68mA/0.34W | USB Auto Scan | Standby Power | 112mA/0.56W | ||||
| Operating Power | 280mA/1.4W | Operating Power | 196mA/0.98W | ||||||
| Max Power | 306mA/1.53W | Max Power | 214mA/1.07W | ||||||
| Serial Port Manual Scan | Standby Power | 68mA/0.34W | Serial Port Auto Scan | Standby Power | 113mA/0.565W | ||||
| Operating Power | 288mA/1.44W | Operating Power | 190mA/0.95W | ||||||
| Max Power | 304mA/1.52W | Max Power | 212mA/1.06W | ||||||
