Overview：
charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers
user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
2）Maximum efficiency 90%.
3）Intelligent fan speed regulation: start to work when the load is greater than 600w, and the fan speed will be controlled according to the load and the internal temperature.
4）1Protection function: low voltage protection, charged over protection, overload protection, short circuit protection, over temperature protection.
5） Application: home, office, vehicle, yacht and other occasions.
Pure Sine Wave Inverter 110V
-
Pure Sine Wave Inverter，12Vdc to 110Vac inverter.
-
battery support 12V system
-
Inverter Max efficieny 90%.
-
Protection: low voltage protection, Overload protection, short circuit protection, Over temperature protection
-
Intelligent fan speed regulation: start to work when the low is greater than 600W,and the fan speed will be controlled according to the load and the internal tempurature.
Important Note: Under normal operation, inverter will “beep” every 30 seconds to let you know inverter is working properly. when a fault happen, inverter will "Beep" every 10S or less to remind you to check the inverter asap.
Pakage included:
-
1*12V DC to 110V AC Inverter(Pure Sine Wave)
-
1*User Manual
-
Important Note: Under normal working conditions, it will “beep” every 30 seconds to let you know inverter is working properly. when a fault happen, it will "Beep" every 10S or less to remind you to check the inverter asap.
| Rated Input Voltage | 12V |
| Rated Current | 112A |
| Maximum Efficiency | 90% |
| Rated AC Ouput Power | 1200W |
| Ouput AC Voltage | 110V |
| Frequency | 60Hz |
| Ouput AC Wave Form | PURE SINE WAVE |
| Battery low voltage Alarm | 10.5V |
| Battery low Voltage Recovery | 11V |
| Battery Low Voltage Shutdown | 10V |
| Output short Circuit | After the fault is eliminated, it can be rebooted |
| Overload protection | 110%<=load<125%, 1minute shutdown; 125%<=load<150%, 30s shutdown; 150%<=load shutdown immediatedly |
| Overtemperature | heat dissipation temparature>90℃, will protection |
| Dimension | 305*172*72mm |
